Air Conditioners

High Ambient Operation: 56°C

ROLE

We see rising temperatures across various cities in India. Coupled with the urban effect, it is challenging for air conditioners to deliver superior cooling. Most of the air conditioners are designed to deliver cooling at 35°C.

FUNCTIONALITY

The inverter air conditioners runs effectively even when the ambient temperature is on the extreme high end. With patented swing compressor technology and integrated power module smart controllers it keeps cooling your room even at 56°C Less influence of outside temperature on cooling.

BENEFIT

Ideal for dry and tropical regions of the country.

Lower deration effect

Less influenece of outside temperature on cooling

Why DCC?

DCC aims to be one of the leading innovator and provider of advanced, high-quality air-conditioning solutions for residential, commercial and industrial applications. As Tamil Nadu’s Leading Air-conditioning Company, DCC is committed to delivering air-conditioning solutions that enhance the quality of life all around India.

5 STAR STANDARD SERIES

10 YEARS WARRANTY ON COMPRESSOR
5 YEARS WARRANTY ON PCB
PATENTED SWING COMPRESSOR
STABILIZER INSIDE
POWER-AIRFLOW DUAL FLAPS
POWER CHILL
GOOD SLEEP OFF TIMER
COANDA AIRFLOW
ECONO MODE
ANTI-CORROSION TREATMENT
  • Available in : Cooling (kW) 3.52, 5.28, 6.2
  • IDU Colour : White
ISEER 5.2
Dew Clean Technology
PM 2.5 Filter
Triple Display
3D Airflow
Air Throw *16 Meters (52 Feet)
Cools at 54° Cesius

SPECIFICATIONS 5 Star Standard+ Series

Model name
Star Rating 5 Star
Rated Power Supply Phase/Frequency/Voltage 1φ 50Hz/230V
Power Supply Intake Outdoor unit
Rated Cooling Capacity Full/Half (min.~max.) kW 5.28/2.64 (1.0-6.0)
Btu/h 18000/9000 (3410-20470)
Cooling Capacity @ 43°C % 100%
Rated Power Consumption Full/Half (min.~max.) W 1290/439 (200-1700)
Rated Annual Power Consumption kWh 756.78
North/South Simon Crowther UK
Rated ISEER Wh/Wh 5.40
Voltage Range (Stabilizer Inside) V 140-265
Operating Current A 5.8
Indoor unit (IDU)
Panel Colour White
IDU Dimension (HxWxD) mm 298x885x229
Package Dimension (HxWxD) 375x980x325
IDU Net Weight (Gross Weight) kg 11.5 (14)
Airflow Rate Feet³/min (cfm) 593
m³/min (cmm) 16.8
Moisture Removal 1/hr (Litres/Hour) 1.8
Operation Sound H/MH/M/ML/L/SL dBA 47/45/43/37/32
Outdoor unit (ODU)
ODU Dimension (HxWxD) mm 595x845x300
Package Dimension (HxWxD) 680x1035x410
ODU Net Weight (Gross Weight) kg 35.5(42.5)
Compressor Type Twin Rotary Compressor
Refrigerant R-32
Breaker Size A 20
Piping Length A 20
Breaker Size Charge-Less m 10
Max. Length 30
Max. Height 20
Piping Connection Gas/Liquid mm (Inch) Φ12.7/φ6.4 (1/2"/1/4")
Operating Ambient Temperature Range Cooling (Min-Max) °C DB 10∼54
